Technologies & solutionsExperience is still the best expertise.
References
Reliable and multifunctional technology – successful in every application
Since 1979 we have been working with our global customers from a wide range of industries to find cost-and energy-saving solutions of the highest quality.
Air conditioning of a fully automated paint shop
Pitești, Romania
- 7 direct evaporation systems
- Total cooling capacity of 1,140 kW
- Recirculating air + fresh air conditioning
- High energy savings through demand-based design
Cooling of moisture-sensitive production processes
Morsbach
- 6 direct evaporation systems
- 2,530 kW cooling capacity, 1,630 kW heating capacity
- Process air conditioning with heat recovery
- Elimination of complex cold-water piping for the customer
Air cooling and dehumidification for food production
Stadtallendorf
- 4 split systems with heat recovery
- 2,400 kW cooling capacity, 1,760 kW heating capacity
- Free of charge reheating with waste heat
- Retrofit thanks to flexible plant design with small footprint
Process air conditioning in surface technology
Mosonmagyaróvár, Hungary
- DX system in split design
- 220 kW cooling capacity, 190 kW heating capacity
- Highest control accuracy
- Dehumidification including reheating with waste heat
Air conditioning of a large logistics centre
Aldenhofen
- combined refrigeration system
- Total cooling capacity of 1,200 kW
- 66 cooling coils with direct evaporation
- Split system for indoor installation with external condenser
Air conditioning of an automotive paint shop
Meppel, Netherlands
- 15 water-cooled systems
- Total cooling capacity of 3,470 kW
- Compact design for decentralized installation
- Including recooling facilities and higher-level control system
Fresh air cooling/dehumidification for paint booths
Gliwice, Poland
- Three-circuit refrigeration system (DX)
- 1,740 kW cooling capacity
- Turnkey solution for the customer
- Maximum efficiency through direct air cooling without chilled water
Dehumidification of process air in surface technology
Regensburg
- Dehumidification system
- 180 kW cooling, 290 kW heating capacity
- Dehumidification capacity: 100 l/h
- Heating of the supply air to 72°C using waste heat from the cooling process
Intermediate dryer for automotive paint shop
Buenos Aires, Argentina
- Condensation dryer in split design
- 895 kW cooling capacity, 764 kW heating capacity
- 3.5 g/kg absolute humidity and 50°C
- Dehumidification with direct evaporation technology
Dry air for the humidity-sensitive food industry
Hannover
- Dehumidification system in compact design
- 80 kW cooling capacity, 110 kW heating capacity
- Compact system for retrofitting
- Including humidity and temperature control of the supply air
Dehumidification system for a recirculating air dryer
Tjanjin, China
- Condensation dryer including ventilation unit
- 805 kW cooling capacity, 795 kW heating capacity
- 32,000 m³/h, dehumidification to 3.8 g/kg
- 6-stage process with heat recovery system
Solvent condensation from process exhaust air
Sunderland, England
- Compact condensation dryer
- 130 kW cooling capacity, 210 kW heating capacity
- Dehumidification capacity: 80 l/h
- Compact design including ventilation technology and heat recovery system
Heat generation for a low – ex district heating network
Bielefeld
- Large air-to-water heat pump system
- Total capacity 720 kWth
- 4 machine set and air cooler each
- Combined operation and adaptive defrosting for maximum seasonal efficiency
Large heat pump system for district heating (iKWK)
Greifswald
- 3 air-water heat pumps + 2 booster water-water heat pumps
- Total capacity 1,800 kWth
- 2-stage heat generation
- Including master control and control of the entire hydraulic system
Intelligent sector coupling with wastewater heat pump
Moosburg
- High-temperature heat pump
- 400 kWth at 90°C
- Outdoor installation including sound insulation
- For sewage sludge drying and district heating feed-in
Cooling water heat recovery from cooling processes
Vienna, Austria
- 2 compact water-water heat pumps
- Total capacity 2,450 kWth
- Designed for maximum part-load efficiency
- Including frequency-controlled compressor + optimized heat exchangers
Simultaneous cold and heat supply for manufacturing processes
Minden
- High-temperature heat pump
- 150 kWth at 90°C
- Custom-specific design
- Maximum efficiency through concurrent cooling and heating
Building heating with an ultra-low-noise air-water heat pump
Bielefeld
- Air-water heat pump in split design
- 155 kWth
- For extremely quiet outdoor installation
- 2 air coolers for continuous heat supply during defrosting
Wastewater heat pump for heating a campus
Giessen
- Low-GWP heat pump (R1234ze)
- 855 kW heating / 500 kW cooling
- Switchable for heating and cooling
- Including hydraulic module with pumps, valves and control system
Exhaust air/supply air heat pump for dryer heating
Krefeld
- Heat pump in split design
- 480 kWth
- Direct evaporation/condensation
- Retrofit to increase efficiency by utilizing free waste heat
High-efficient cooling of process bath for car body painting
Ludwigsfelde
- Chiller unit including free cooling
- 500 kW / 200 kW free cooling
- Ultra-low noise exterior housing
- Highest efficiency for optimal seasonal performance
Production cooling with heat recovery
Warendorf
- Chiller unit with heat recovery
- 390 kW cooling / 500 kW heating
- High-efficiency design
- Refrigeration system with variable heat recovery and residual heat condenser
Chiller unit with low-GWP refrigerant
Lüdenscheid
- A2L chiller unit in split design
- 620 kW cooling capacity
- 2 fully redundant circuits
- In a weatherproof housing including frost protection and primary pumps
Peak-load cooling for process water in the furniture industry
Kirchlengern
- 3 separate chillers
- Total cooling capacity of 850 kW
- Split design
- External, air-cooled condensers in low-noise design
Customized refrigeration system for automotive supplier
Feuchtwangen
- Chiller unit in compact design
- 750 kW / 500 kW free cooling
- Redundant design
- For maximum availability, including hydraulic module + free cooling
Simultaneous cooling and heating supply for production
Kalkar
- Chiller unit in compact design
- 490 kW cooling / 720 kW heating
- 100% waste heat utilization
- Designed for maximum efficiency
Cooling of an engine test bench for a German automobile manufacturer
Wolfsburg
- Low-temperature cooling
- 35 kW at -50°C thermal oil
- Including buffer tank and pump
- Custom design including factory specifications
Low temperature technology for test bench cooling
Salzgitter
- 2-stage refrigeration system
- 32 kW at -45°C brine
- Compact, water-cooled design
- Including hydraulic accessories such as buffer tank and pump
Booster cooling for a test laboratory for moving components
Gütersloh
- Deep cooling with direct evaporation
- 12 kW at -38°C air temperature
- Split, air-cooled design
- Peak load cooling for an environmental simulation facility
CO2 liquefaction in a biogas plant
Aschhofen
- Deep cooling using direct evaporation
- 180 kW at -37°C
- Air-cooled design including ECO and oil cooler
- Including a customized control concept for optimal integration into the process
